Folding Ladder

Design No.AL-251/8804

ALUMINIUM STOOL TYPE LADDER
  • Description: Aluminium self supporting stool type folding ladder made out of high tensile aluminium Alloy along with Al. Platform fitted with hinge and rubber pads at lower bottom ends.
  • Side: Al. ‘C’ Shape section of size 66.6 x 31.7mm.
  • Step: 25mm dia Non- Slippery corrugated Tubing on front and 25mm dia corrugated non slippery on back..
  • All Aluminium Raw Material used(Alloy & Temper) confirming to(IS-733-1975)(latest).
  • Description: HEIGHT AVAILABLE FT. (Mtrs.) All Size Available 4’Ft (1.22) to 24’Ft(7.32).
  • 4’(1.22).
  • 6’(1.83).
  • 8’( 2.44).
  • 10’(3.04).
  • 12’(3.66).
  • 14’(4.27).
  • 16’(4.88).
  • 18’(5.49).
  • 20’(6.09).
  • 24’(7.32).

  • Other Heavy Duty options are also available
    FRP Ladders for same design are available

Design No.AL-201/8818

ALUMINIUM STOOL TYPE LADDER
  • Description: Aluminium self supporting stool type folding ladder made out of high tensile aluminium Alloy along with Al. Platform fitted with hinge and rubber pads at lower bottom ends.
  • Side: Al. ‘C’ Shape section of size 66.6 x 31.7mm.
  • Step: 63mm dia Non- Slippery corrugated Tubing on front and 25mm dia corrugated non slippery on back..
  • All Aluminium Raw Material used(Alloy & Temper) confirming to(IS-733-1975)(latest).
  • Description: HEIGHT AVAILABLE FT. (Mtrs.) All Size Available 4’Ft (1.22) to 24’Ft(7.32).
  • 4’(1.22).
  • 6’(1.83).
  • 8’( 2.44).
  • 10’(3.04).
  • 12’(3.66).
  • 14’(4.27).
  • 16’(4.88).
  • 18’(5.49).
  • 20’(6.09).
  • 24’(7.32).

  • Other Heavy Duty options are also available
    FRP Ladders for same design are available

Design No.AL-8821

ALUMINIUM STOOL FOLDING LADDER
  • Description: Aluminium self supporting stool type folding ladder made out of high tensile aluminium Alloy along with Al. Platform fitted with hinge and rubber pads at lower bottom ends..
  • Side: Al. ‘C’ Shape section of size 66.6 x 31.7mm.
  • Step: 112mm wide one piece step edging Non- Slippery corrugated on front and 63mm wide one step corrugated non slippery on back.
  • All Aluminium Raw Material used(Alloy & Temper) confirming to(IS-733-1975)(latest).
  • Description: HEIGHT AVAILABLE FT. (Mtrs.) All Size Available 4’Ft (1.22) to 24’Ft(7.32).
  • 4’(1.22).
  • 6’(1.83).
  • 8’( 2.44).
  • 10’(3.04).
  • 12’(3.66).
  • 14’(4.27).
  • 16’(4.88).
  • 18’(5.49).
  • 20’(6.09).
  • 24’(7.32).

  • Other Heavy Duty options are also available
    FRP Ladders for same design are available

Design No.AL-351/8812

ALUMINIUM DOUBLE STEP LADDER
  • Description: Aluminium self supporting stool type folding ladder made out of high tensile aluminium Alloy along with Al. Platform fitted with hinge and rubber pads at lower bottom ends.
  • Al. ‘C’ Shape section of size 66.6 x 31.7mm.
  • Step: 63mm wide one piece step edging Non- Slippery corrugated on front and 25mm wide one step corrugated non slippery on back.
  • All Aluminium Raw Material used(Alloy & Temper) confirming to(IS-733-1975)(latest).
  • Description: HEIGHT AVAILABLE FT. (Mtrs.) All Size Available 4’Ft (1.22) to 24’Ft(7.32).
  • 4’(1.22).
  • 6’(1.83).
  • 8’( 2.44).
  • 10’(3.04).
  • 12’(3.66).
  • 14’(4.27).
  • 16’(4.88).
  • 18’(5.49).
  • 20’(6.09).
  • 24’(7.32).

  • Other Heavy Duty options are also available
    FRP Ladders for same design are available

Design No.AL-451/8814

ALUMINIUM FACTORY STEP SELF SUPPORTING LADDER
  • Description: Aluminium factory step self supporting stool type ladder made of high tensile aluminium Alloy fitted with one tool tray on the top and one platform 3ft.Below from the top as working man platform along with hinge and rubber pads at lower bottom ends.
  • Side: Al. ‘C’ Shape section of size 66.6 x 31.7mm.
  • Step: 63mm wide one piece step edging Non- Slippery corrugated on front and 25mm wide one step corrugated non slippery on back.
  • All Aluminium Raw Material used(Alloy & Temper) confirming to(IS-733-1975)(latest).
  • Description: HEIGHT AVAILABLE FT. (Mtrs.) All Size Available 4’Ft (1.22) to 24’Ft(7.32).
  • 4’(1.22).
  • 6’(1.83).
  • 8’( 2.44).
  • 10’(3.04).
  • 12’(3.66).
  • 14’(4.27).
  • 16’(4.88).
  • 18’(5.49).
  • 20’(6.09).
  • 24’(7.32).

  • Other Heavy Duty options are also available
    FRP Ladders for same design are available

Design No.AL-8820

ALUMINIUM STOOL CUM STRAIGHT LADDER
  • Description: Aluminium stool cum straight ladder (convertable type)made out of Aluminium one piece step edging with platform on the top (when stool type).
  • Side: Al. ‘C’ Shape section of size 66.6 x 31.7mm.
  • Step: 63mm wide one piece step edging Non- Slippery corrugated on front and 63mm wide corrugated non slippery on back..
  • All Aluminium Raw Material used(Alloy & Temper) confirming to(IS-733-1975)(latest).
  • Description: HEIGHT AVAILABLE FT. (Mtrs.) All Size Available 4’Ft (1.22) to 24’Ft(7.32).

  • Stool Position
  • 5’(1.52).
  • 6’(1.82).
  • 7’(2.13).

  • Straight Position
  • 8’(2.44).
  • 10’(3.04).
  • 12’(3.66).

  • Other Heavy Duty options are also available
    FRP Ladders for same design are available

Design No.AL – 8817

Aluminum Double Step Trestle Ladder
  • Side: Aluminium ‘C’ shapes section of size 66.6×31.7mm.
  • Step: Front side 63mm wide steps & back side 25mm dia round corrugated tube..
  • Fitted with Auto Folding Platform 1 Ft. below from top. Bottom end with non slippery rubber pad Material used as per IS: 733-1983.
